Product Summary

The SMS3PHGE4 is a SMS QIKMATE connector. It offers economy to meet the constant demand for more cost-effective interconnection techniques. The SMS3PHGE4 is available as sell mountable receptacies, plugs, boardmounts, P.C. pin headers and accessories.

Parametrics

SMS3PHGE4 specifications: (1)Operating temperature: -55℃ to +105℃; (2)Insulation resistance: 5000MΩmin; (3)Test potential: 2000VAC; (4)Current rating boardmount: 5Amp; (5)Contact resistance boardmount: ≤6mΩ; (6)Durability: 500 cycles.

Features

SMS3PHGE4 features: (1)Self mountable receptacle with positive housing retention; (2)Error-free mating with positive connector polarization; (3)Plugs with retaining latches for positive locking; (4)Plugs with pin protection skirt to prevent damage of male contacts; (5)Boardmounts available with stamped and formed or solid machined contacts.

Diagrams

SMS3PHGE4 dimensions

SMS30752
SMS30752
Glenair
Circular MIL / Spec Tools, Hardware & Accessories
Data Sheet
