Product Summary

The TPSC686K010R0080 is a tantalum capacitor, which has inherently low ESR (equivalent series resistance)and is capable of higher ripple current handling, producing lower ripple voltages, less power and heat dissipation than standard product for the most efficient use of circuit power. The TPSC686K010R0080 has been designed, manufactured, and preconditioned for optimum performance in typical power supply applications.

Parametrics

TPSC686K010R0080 technical specifications: (1)Capacitance Range: 0.15 μF to 1500 μF; (2)Capacitance Tolerance: ±10%; ±20%; (3)Rated Voltage (VR) ≤ +85℃: 10V; (4)Category Voltage (VC) ≤ +125℃: 7V; (5)Surge Voltage (VS) ≤ +85℃: 13V; (6)Surge Voltage (VS) ≤ +125℃: 8V; (7)Temperature Range: -55℃ to +125℃; (8)Environmental Classification: 55/125/56 (IEC 68-2); (9)Reliability: 1% per 1000 hours at 85℃, VR with 0.1Ω/V series impedance, 60% confidence level; (10)Termination Finished: Sn Plating (standard), Gold and SnPb Plating upon request.

Features

TPSC686K010R0080 features: (1)Low ESR series of robust Mn02 solid electrolyte capacitors; (2)CV range: 0.15-1500μF/ 2.5-50V; (3)14 case sizes available; (4)Power supply applications.

Diagrams

TPSC686K010R0080 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TPSC686K010R0080
TPSC686K010R0080
AVX
Tantalum Capacitors - Solid SMD 10V 68uF 10% Tol. 80 ESR
Data Sheet
0-1: $2.23
1-50: $1.86
50-100: $1.49
100-500: $1.12
